60 BPM Fully Automatic Turnkey Project for Goli Soda
Our Products
Watch Product Video
The 60 BPM Fully Automatic Turnkey Project for Goli Soda is a comprehensive solution for efficient production of Goli Soda. This 60 BPM Automatic Turnkey Project for Goli Soda integrates rinsing, filling, capping, and packaging processes, delivering a seamless and high-speed production experience of up to 60 bottles per minute. Designed as a 60 BPM Complete Goli Soda Plant Turnkey Project, it ensures consistent product quality, minimizes operational downtime, and caters to the needs of small to medium-scale soda manufacturers. Perfect for businesses seeking reliability, precision, and cost-effectiveness in Goli Soda production.
| Category | Details |
|---|---|
| Machine Category | High Speed Semi Automatic |
| Machine Model | DM-BKHSE2 |
| No. of Cavities | 2 Cavity |
| Production Capacity (Bottles/Hour) | – 2200BPH for 300ml (Depending on Moulds and Pre-form Quality) |
| Blowing Capacity | 100ml – 2000ml |
| Bottle Outlet | Auto Drop |
| Size of the Mould (Width x Thickness) | 120mm x 125mm (Each) |
| Category | Details |
|---|---|
| Types of Bottles Blowing | Water, Juice & Soda |
| Types of Preform | Alaska & PCO |
| Max. Neck Diameter | 28mm |
| Max. Diameter of Bottle | 102mm |
| Max. Height of the Bottle | 340mm |
| Category | Details |
|---|---|
| Pre-heating System | Near Infrared |
| No. of Heaters | 8 Nos |
| Heater Capacity | 2000 Watts |
| Machine Connected Power | 5KW, 3 Phase |
| Machine with Accessories Connected Power | 23KW, 3 Phase |
| Total Power Consumption (Including Accessories) | 16KWH (Units) |
| Category | Details |
|---|---|
| Blowing Pressure | 20Bar |
| Working Pressure | 6Bar |
| Air Consumption | 38CFM |
| Category | Details |
|---|---|
| Compressor Capacity (High Pressure) | 20HP/25Bar/54CFM |
| Water Chiller Capacity | 2.5Ton @ 10°C |
How It Works
Bottles are automatically fed into the system and cleaned using high-pressure water jets to ensure hygiene and prepare them for filling.
The system fills the bottles with Goli Soda using advanced technology that maintains carbonation and ensures accurate filling.
The iconic Goli Soda caps are securely sealed onto the bottles using a fully automated capping mechanism, ensuring leak-proof and tamper-resistant packaging.
Finished bottles are neatly packaged and discharged for further inspection or distribution, ready to reach the market.
Water
Juice
Carbonated Soft Drinks
Food
Beverages
- Handles up to 60 bottles per minute, ensuring high-speed production for Goli Soda.
- Provides end-to-end integration of rinsing, filling, capping, and packaging for seamless operations.
- Maintains hygiene and carbonation quality, ensuring consistent taste and product standards.
- Reduces labor costs with fully automated processes and minimizes production downtime.
- Built with robust materials for durability and long-lasting performance.
- Customizable design to accommodate specific production needs and bottle sizes.
Key Features of Dunamis Machines
High-Pressure Rinsing System
Ensures thorough cleaning of bottles before the filling process.
Accurate Filling Mechanism
Maintains carbonation while ensuring precise filling levels in every bottle.
Automated Capping System
Efficiently seals bottles with Goli Soda caps for leak-proof packaging.
60 BPM Production Speed
Produces up to 60 bottles per minute for small to medium-scale manufacturing.
Streamlined Packaging Solution
Neatly packages finished bottles for easy distribution.
User-Friendly Controls
Simplifies operation with an intuitive interface for easy monitoring and adjustments.
