120 BPM Fully Automatic RFC Machine
Our Products
Watch Product Video
The 120 BPM Fully Automatic RFC Machine is a high-speed solution for rinsing, filling, and capping mineral water bottles with unmatched precision and efficiency. Designed for large-scale operations, this 120 BPM Fully Automatic RFC Filling Machine delivers a seamless production flow, handling up to 120 bottles per minute. As a reliable 120 BPM Mineral Water Filling Machine, it ensures consistent water levels, hygiene, and superior quality. The 120 BPM Automatic Mineral Water Bottle Filling Machine is the perfect choice for businesses seeking productivity, accuracy, and smooth operation.
| Category | Details |
|---|---|
| Machine Model | DM-WF120E |
| Machine Category | Fully Automatic |
| Types of Operation | Rinsing, Filling & Capping |
| Production Capacity | 7200 BPH – 9000 BPH |
| Bottle Feeding | Through Air Conveyor |
| Air Conveyor Length | 6 Mtrs |
| Number of Rinsing Nozzles | 18 Nos |
| Filling Volume | 150ml – 2000ml |
| Number of Filling Valves | 12 Nos |
| Number of Capping Head | 8 Nos |
| Out-feed Conveyor Length | 9 Mtrs |
| Shrink Tunnel | Electrical Type |
| Category | Details |
|---|---|
| Types of Bottles Filling | Water Bottle |
| Bottle Neck Dia | 28mm, Alaska Neck |
| Max Container Dia | 105mm |
| Max Container Height | 350mm |
| Category | Details |
|---|---|
| Machine Connected Power | 12.5HP / 9.5KW, 3Phase (Include Shrink Tunnel) |
| Machine Power Consumption | 7.5KWH |
| Type of Electrical Panel | PLC Based Control Panel with HMI |
| Electrical Supply | 3 Phase with Neutral, 415Volt, 50 HZ |
How It Works
Empty bottles are automatically fed into the 120 BPM Fully Automatic RFC Machine, where high-pressure water jets clean the bottles to ensure hygiene and quality.
The rinsed bottles are precisely filled with mineral water through an automated 120 BPM Fully Automatic RFC Filling Machine mechanism, ensuring uniform water levels.
After filling, the bottles are seamlessly capped with precision using an automated capping system to guarantee leak-proof sealing.
Once capped, bottles are automatically ejected from the machine, ready for labeling, packaging, or further processing, ensuring a smooth production flow.
Water
Juice
Carbonated Soft Drinks
Food
Beverages
- High-speed production capacity of 120 bottles per minute, ideal for large-scale operations.
- Ensures hygienic rinsing, precise filling, and leak-proof capping for consistent quality.
- Fully automated operation reduces labor requirements and improves productivity.
- Maintains accuracy and minimizes wastage with a precise filling mechanism.
- Reliable performance for long-term use with a robust and durable build.
- Seamless integration into production lines, optimizing overall efficiency.
Key Features of Dunamis Machines
High-Speed Operation
Capable of producing up to 120 bottles per minute, ensuring efficient and large-scale mineral water production.
Precision Filling System
Automated filling technology guarantees accurate water levels, reducing wastage and ensuring consistency.
Advanced Bottle Rinsing
Equipped with high-pressure water jets for thorough bottle cleaning, ensuring superior hygiene.
Automated Capping Mechanism
Leak-proof capping system provides reliable sealing to maintain product safety and quality.
User-Friendly Controls
Intuitive controls make the machine easy to operate, reducing manual effort and streamlining workflow.
Energy-Efficient Design
Optimized power consumption minimizes operational costs while delivering high-performance output.
